>Doosan engines imported from South Korea
>Turbo charged & intercooled (air to air), low noise, excellent emission
>Small cubage, light weight, high stability under suddend loading, low noise, few fault, economized and reliable
>Stable performance, compact structure, big capacity, low consumption,cost-effective maintenance |
|
|
|
|
|
|
|
| | Genset Model | POWER | Engine Model | Controller | Fuel Consumption (L/H) 100% | Open Genset | Soundproof Genset | | Dimension ＆ Weight | Dimension ＆ Weight | Standby (kVA)
PF:0.8 | Prime (kVA)
PF:0.8 | Dimension
(L×W×H）mm | Weight (kg) | Dimension
(L×W×H）mm | Weight (kg) | | FKS-D68 | 68 | 62 | DB58 | DSE6020 | 13 | 2050×800×1000 | 820 | 2400×1000×1550 | 1350 | | FKS-D87 | 87 | 80 | D1146 | DSE6020 | 16 | 2370×790×1200 | 1050 | 2700×1100×1650 | 1500 | | FKS-D125 | 125 | 115 | D1146T | DSE6020 | 21 | 2370×790×1200 | 1160 | 3300×1200×1800 | 2100 | | FKS-D165 | 165 | 150 | P086TA | DSE6020 | 28 | 2600×1000×1500 | 1750 | 3300×1200×1800 | 2200 | | FKS-D181 | 181 | 165 | P086TI-1 | DSE6020 | 33 | 2600×1000×1500 | 1750 | 3300×1200×1800 | 2500 | | FKS-D225 | 225 | 200 | P087TI | DSE6020 | 43.1 | 2680×950×1430 | 2200 | 3300×1200×1850 | 3000 | | FKS-D250 | 250 | 225 | DP086LA | DSE6020 | 45 | 2680×950×1430 | 2200 | 3600×1300×2100 | 3300 | | FKS-D300 | 300 | 275 | P126TI | DSE7320 | 58.1 | 2910×1050×1530 | 2450 | 3600×1300×2100 | 3600 | | FKS-D325 | 325 | 300 | P126TI-11 | DSE7320 | 63.1 | 2910×1050×1530 | 2450 | 4000×1400×2100 | 3800 | | FKS-D400 | 400 | 360 | P158LE-1 | DSE7320 | 78.7 | 3120×1390×1830 | 2930 | 4300×1500×2200 | 4400 | | FKS-D462 | 462 | 400 | P158LE | DSE7320 | 89.3 | 3120×1390×1830 | 2950 | 4300×1500×2200 | 4800 | | FKS-D500 | 500 | 452 | DP158LCF | DSE7320 | 98 | 3120×1390×1830 | 3150 | 4300×1500×2200 | 5200 | | FKS-D575 | 575 | 525 | DP158LDF | DSE7320 | 115 | 3295×1390×1830 | 3500 | 4800×1800×2500 | 5500 | | FKS-D625 | 625 | 570 | DP180LAF | DSE7320 | 134 | 3295×1390×1830 | 4000 | 4800×1800×2500 | 6000 | | FKS-D687 | 687 | 625 | DP180LBF | DSE7320 | 150 | 3450×1390×1840 | 4500 | 4800×1800×2500 | 6500 | | FKS-D750 | 750 | 687 | DP222LBF | DSE7320 | 160 | 3450×1390×1840 | 5000 | 5000×2000×2600 | 7000 | | FKS-D825 | 825 | 750 | DP222LCF | DSE7320 | 170 | 3450×1390×1850 | 5500 | 5000×2000×2600 | 7500 |
|
